‌Brief Introduction

Shanghai Heat Transfer Equipment Co., Ltd. (SHPHE in short) is specialized in design, manufacturing, installation and service of plate heat exchangers.

With advanced engineering and manufacturing technology, comprehensive heat exchanger expertise and rich service experiences, SHPHE dedicates to supply quality plate heat exchangers to various clients worldwide in oil and gas, chemical, power plant, bio-energy, metallurgy, marine, HVAC, mechanical manufacturing, paper & pulp, steel, etc.

SHPHE remains committed to driving industry progress through continuous technological innovation. By partnering with leading companies at home and abroad, SHPHE aims to become a top-tier provider of high-quality solutions in the heat exchange industry, both in China and internationally.

2005

FOUNDED IN 2005
16+

MORE THAN 16 PRODUCTS
20+

EXPORTED COUNTRIES
20000㎡

FACTORY AREA

Global Footprint

canada
USA
Jamaica
Venezuela
Brazil
RUSSIA
china
MALAYSIA
Singapoare
Indonesia
AUSTRALIA
Norway
Mauritius
France
Germany
Romania
Turkiye
Greece
Iran
UAE

During the past decades, the products of SHPHE have been exported to US, Canada, Australia, Russia, Greece, Romania, Malaysia, India, Indonesia, etc.

Facilities

SHPHE has over thirty different invention, patents and copyrights. Engineers and technicians accounts for 40% of total employees. It has advanced technology in thermal sizing, engineering and simulation. Facilities such as 60MN/200MN high precision press, 2mx15m automatic electric resistant /arc welding machine, automatic multi-spot welding machine, TIG welding machine ensure the hardware capability for manufacturing different plate heat exchangers.

Concepts of R&D

Listening to Nature

Every researcher draws inspiration from nature’s energy transfer, applying biomimicry principles to meet customer requirements while maximizing safety and energy efficiency. Our latest wide-channel welded plate heat exchangers improve heat transfer efficiency by 15% compared to traditional models. By studying natural energy transfer phenomena—such as how fish reduce drag while swimming or how ripples transfer energy in water—we integrate these principles into product design. This combination of biomimicry and advanced engineering pushes the performance of our heat exchangers to new heights, fully harnessing the wonders of nature in their design.
Minimizing Energy Consumption

At the same heat exchange capacity, SHPHE’s removable plate heat exchangers are designed to use the least amount of energy. From research and development to design, simulation, and precision manufacturing, we ensure optimal product performance. SHPHE offers over 10 series of top-tier energy-efficient products, including models with over 350 corner holes at the highest efficiency level. Compared to 3rd-level energy-efficient plate heat exchangers, our E45 model, processing 2000m³/h, can save approximately 22 tons of standard coal annually and reduce CO2 emissions by around 60 tons.
Customized

Product development can be tailored to meet the specific needs of users, ensuring a high degree of customization. We work closely with clients to gather detailed insights into their needs and expectations, allowing us to tailor our product development process accordingly. Throughout the research and development design stage, we employ cutting-edge technologies and methodologies to ensure that our products are engineered to the highest standards. We conduct rigorous testing and analysis to validate the design and make necessary adjustments to optimize performance. This attention to detail ensures that our products can withstand extreme pressures and temperatures while maintaining efficient heat transfer.
Integrate Digital Technologies

SHPHE has integrated modern digital technologies such as cloud computing, big data, and the internet to create a digital service platform focused on both manufacturing and services. This platform offers smart, comprehensive heat transfer solutions that make customer operations safer, more efficient, and intelligent. With a dedicated research and development team, SHPHE has developed energy-saving technologies that improve energy efficiency. The company has successfully launched several large-scale plate heat exchangers that meet China’s top energy efficiency standards, playing a key role in advancing the country's Carbon Peak and Carbon Neutrality strategy.

Development History

2005-2025

Shanghai Heat Transfer
2025

Successfully developed special PHE skid for marine working conditions, which has been applied to the largest offshore oil & gas platform in the Bohai Sea.
2024

Successfully developed large scale HT- BLOC WPHE with 6.4 MPa design pressure and 410℃ design temperature
2023

Successfully developed acrylic acid overhead condensers with 7300m² heat transfer area per unit
2022

Successfully developed, designed, and manufactured a pressure resistant 9.6MPa built-in plate heater for the stripping tower
2021

Participated in drafting the National Energy Industry Standard (NB/T 47004.2-2021) - Plate Heat Exchanger Part 2: Welded Plate Heat Exchanger
2020

Obtained certification for the Integration of Informatization and Industrialization Management System
2019

Obtained energy-saving registration certificate for plate heat exchangers；
China’s First Project for Localized Production of Large-Scale Plate Heat Exchangers for Offshore Oil Platforms
2018

Obtain the HTRI membership certificate from the American Heat Transfer Association
2017

Participated in drafting the National Energy Industry Standard (NB/T 47004.1-2017) - Plate heat exchangers - Part 1: Plate-and-frame heat exchangers
2015

The first domestically developed vertical wide channel welded plate heat exchanger applied in the alumina industry;Successfully developed and designed a high-pressure plate heat exchanger with a pressure of 3.6MPa
2014

Successfully developed plate air preheaters for natural gas hydrogen production, tail gas treatment, and other applications;The first domestically developed flue gas heat exchanger successfully applied to steam condensing boiler systems
2013

Successfully developed and applied plate type dehumidification devices for inert gas storage systems in ocean going oil tankers and chemical tankers
2012

Obtained ASME certification
2009

Certified to ISO 9001, ISO 14001, and ISO 45001
2007

Mass production of Gasketed plate heat exchanger
2006

Mass production of wide-gap welded plate heat exchanger
2005

Establishment of our Shanghai manufacturing facility
